Impressive Repairability: Valve Steam Controller Tear-Down & Disassembly
Audio Summary
AI Summary
This is a teardown of the Steam Controller, focusing strictly on its mechanical disassembling and repairability. The aim is to assess how it comes together, hoping to avoid the need for excessive glue, Dremels, saws, or angle grinders, which have been necessary for other controllers in the past. The video is sponsored by Arctic and their MX7 thermal paste, a higher viscosity paste intended for longer endurance applications, with Arctic also providing a website to check for counterfeit products.
Externally, the Steam Controller is composed of two shell halves, with a USBC port in the middle. The back features seven Torx 6 screw holes, none hidden under stickers, which is a welcome change from some previous controllers. The controller includes a D-pad, four face buttons, and Valve's special feature: TMR sticks. There are also two touchpads for laptop-like input, a Steam button, and additional buttons on the back where the hand rests. A wireless puck is included for connectivity and charging.
To begin the teardown, a Torx 6 driver is used to remove the seven screws holding the back shell. The back is a simple plastic shell, with the grip and bumper buttons utilizing plastic springs, a common and straightforward mechanism in controllers. Contact pads are present for connecting to the back pins, and charging pins for the puck are also visible.
The first internal step is disconnecting the battery to prevent any short circuits. The battery removal process is remarkably easy, demonstrating excellent repairability. It's secured by seven screws, with no glue or cables; it uses direct pad contact via gold pads. This design is highly advantageous, as the battery is often the first component to fail. The battery is a lithium-ion unit, 3.85 volts, 2,178 milliamp-hours, with a limited charging voltage of 4.39 volts and a rated energy of 8.39 watt-hours. Valve has a history of providing replacement parts, often through iFixit, and this easy-to-remove battery suggests they will continue this practice for frequently failing components.
After removing the battery, two more Torx screws secure a plastic battery cage, which contains a piece of foam for fit and stability. Beneath this cage is the main board, which handles connections to satellite components like rumble and gyro, and likely the wireless or Bluetooth antenna. The screws for the battery cage are a different size from the exterior screws, highlighting the importance of keeping screws organized during disassembly.
The main board reveals an MS2833 controller module. Removing the board requires taking out a few more screws and carefully disconnecting thin, fragile cables. A notable feature is Valve's clear, plain English labeling for all connections, such as "mainboard P2 contacts down." This is excellent for repairability, as it makes reassembly much easier without needing reference photos or decoding complex alphanumeric labels. This clear labeling also benefits modders by simplifying the creation of an ecosystem for modifications. The board also has a date stamp of September 12, 2025, suggesting these units may have been manufactured some time ago.
The screws for the main board are the same type as those in the battery cage, meaning only two types of screws have been encountered so far, which simplifies the process. Once the board is free, the TMR sticks are visible on the underside, connected via soldered blue cables that are also glued to contact pads. While glue makes replacement slightly less straightforward, it's not the worst obstruction. The main board also features contacts and a pad that corresponds to a cable routing data to the triggers and bumpers.
An interesting observation is a piece of metal on the main board, believed to be the antenna, positioned at the top of the controller. This placement aims to minimize signal interference by being away from other electronics and, crucially, away from users' hands. Other components on the board include an IR LED next to the status LED, used for tracking by the Steam Frame, grip sensors in the handles, a six-axis IMU for gyro, and a magnet for connection to the charging puck.
The next component is the FSC board, which is harder to access. It requires removing additional screws and a rod that acts as a hinge for the trigger mechanism. This rod can be pulled out, providing access to the final two screws for the plastic frame. Once these are removed, the internal structure where all the buttons contact is revealed. The D-pad and face buttons use carbon pads for contact. The bumpers operate on plastic hinges, pressing down on a rubber contact to send signals through exposed traces that lead back to the main board.
Further internal exploration reveals more PCBs underneath, reminiscent of the Steam Deck, though easier to disassemble. Four screws, different in length and type from previous ones, secure this layer. This is the FSC board, featuring probe points for debugging and traces correlating to the touchpads. This board also has a QR code, as do many other components and even the plastic housing. The prevalence of QR codes suggests Valve is preparing to provide repair materials or partner with others to do so.
The teardown concludes, having taken approximately 44 minutes. The process was straightforward, with no stripped screws or Dremel use. The key takeaways are the excellent repairability, highlighted by clear, human-readable labeling, easy battery removal, and the pervasive QR codes that will aid in identifying and replacing parts. This approach to repairability is highly valued, especially for peripherals that may become obsolete, allowing users to maintain their preferred controllers for longer.
